| Image Sensor | 1/2.9" (5 MP) progressive scan CMOS |
| Minimum Illumination | Color: 0.8 lux @ (f/1.6, AGC on), 0 lux with IR |
| Shutter Speed | 1/3 s to 1/100, 000 s |
| Auto-Iris | No |
| S/N Ratio | >56 dB |
| Day/Night | IR cut filter |
| Min. Illumination | Color 0.1lux/F1.6 B/W 0.01lux/F1.6 |
| Digital Noise Reduction | 3D DNR |
| Motion Detection | OFF/ON |
| Human Detection | OFF/ON |
| Angle Adjustment (Bracket) | Pan: 0° to 360°, tilt: 0° to 75*, rotation: 0° to 360° |
| Focal Length | 2.8 mm |
| Aperture | f/1.6 |
| Focus | Manual |
| FOV | 2.8mm, horizontal FOV 113°, vertical FOV 58°, diagonal FOV 123°
3.6mm, horizontal FOV 93°, vertical FOV 45°, diagonal FOV 99° |
| Lens Mount | M12 |
| IR Range | Up to100 ft (30m) |
| Wavelength | 850 nm |
| Maximum Resolution | 2880 x 1616 |
| Main Stream | 30 fps (2880 x 1616, 2560 x 1440, 1920 x 1080) |
| Sub-Stream | 30 fps (704x576,640x480,640x360,352x288) |
| Image Enhancement | BLC, 3D DNR |
| Image Setting | Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser |
| Day/Night Switch | Day/night/auto/schedule |
| Network Storage | Supports local storage |
| Alarm Trigger | Motion detection, network disconnected, IP address conflict, illegal login, |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6 |
| General Function | One-key reset, anti-flicker, two streams, mirror, password protection, privacy mask, IP address filter |
| API | ONVIF |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users; two levels: administrator and user |
| Web Browser | IE,Google |
| Communication Interface | 1-port RJ-45 10M/100M self-adaptive Ethernet port |
| SVC | H.264 and H.265 encoding |
| Operating Conditions | -10° to 50°C; humidity: 95% or less (non-condensing) |
| Power Supply | 12V DC +25%,φ5.5 mm coaxial power plug; PoE (802.3af, class 3) |
| Power Consumption and Current | 12V DC, 0.4 A, maximum: 5 W; PoE (802.3af, 37 V to 57 V), 0.2A to 0.1 A, maximum: 6.5 W |
| Protection Level | IP67, TVS 2000V lightning protection, surge protection and voltage transient protection |
| Material | Metal |
| Dimensions | Camera: φ130.00mm x 95.3mm |
| Weight | Camera: 1.20 Ibs (550 g) |
