HBE-NC-YAP20A3
Highbright
HBE-NC-YAP20A3
Availability: | |
---|---|
Quantity: | |
Sensor Type | 1/2.8 inch CMOS |
Pixel Count | 2 million |
Maximum Resolution | 1920 × 1080 |
Maximum Fill Light Distance | 30m (infrared) |
Adjustment Angle | Horizontal: 0 °~360 ° Vertical: 0 °~90 ° Rotation: 0 °~360 ° |
Shell Material | metal+plastic |
Product Size | 180.0mm × 83.3mm × 114.8mm (length × width × height) |
Packaging Dimensions | 252mm × 137mm × 113mm (length × width × height) |
Net Weight | 0.39kg |
Gross Weight | 0.66kg |
Installation Method | Wall mounted; Top mounted; Pole installation |
Power Supply | Standard |
Working Voltage | DC12V (± 30%) |
Basic Power Consumption | 2.2W (DC12V) |
Working Temperature | -30 ℃~+60 ℃ |
Working Humidity | ≤ 95% |
Lens | Standard Configuration |
Lens Type | Fixed Focus |
Lens Interface | M12 |
Day Night Conversion | ICR automatic switching |
Alarm Event | Network disconnection; IP conflict; Mobile detection; Video occlusion; Illegal access |
Network Interface | 1 (RJ-45 Ethernet port, supporting 10M/100M network data) |
User Management | Supports up to 20 users |
